Kia Sportage: Checking the amount of air conditioner refrigerant and compressor lubricant
When the amount of refrigerant is low, the performance of the air conditioning is reduced. Overfilling also has a negative impact on the air conditioning system.
Therefore, if abnormal operation is found, have the system inspected by an authorized Kia dealer.
WARNING
The oil and refrigerant in your vehicle's air conditioning system is under very high pressure. If proper service procedures are not followed, an explosion may result. To reduce the risk of serious injury or death, the air conditioning system in your vehicle should only be serviced by trained and certified technicians.
CAUTION
It is important that the correct type and amount of oil and refrigerant is used, otherwise damage to the vehicle may occur. To prevent damage, the air conditioning system in your vehicle should only be serviced by trained and certified technicians.
WARNING
Vehicles equipped with R-1234yf*
Since the refrigerant is mildly flammable
and operated at high pressure, the air
conditioning system should only be serviced
by trained and certified technicians.
It is important that the correct type and amount of oil and refrigerant are used.
All refrigerants should be reclaimed with proper equipment. Venting refrigerants directly to the atmosphere is harmful to individuals and environment. Failure to heed these warnings can lead to serious injuries.
